Impress® 316L High Quality Stainless Steel Press Fit System

Impress® 316L high quality stainless-steel press fit system is a single sided press fit system with quality behind it. Wishing you could experience the advantages of press fit but could never quite get the size range you were looking for? With high strength pressure ratings and a size range from 15mm-168mm, you have just found your answer. Impress has been the choice for many of IBEX Australia’s clients as the solution to conventional methods of pipe joining. Contact our friendly staff today for a quotation or retain our details for your next project.

Why Impress?

Cost Savings
  • More than 10 x QUICKER than conventional welding
  • Quick & Easy to Install
  • No Consumables
  • Press Fit Technology
  • Connection Consistency
Installation Advantages
  • Simple tools – user friendly
  • No welding or hot work permits
  • Extensive press tool compatibility
  • Wide range of pipe sizes – 15mm to 168mm
  • Extensive range of fittings
  • Multiple international approvals
  • Built in – situ
  • OH&S friendly
  • Environmentally friendly
Technical Advantages
  • IMPRESS – Quality 316L Series
  • Range of O-rings for special applications
  • Vast temperature range – 20°C to 200°C
  • Technical support & training
Operating Pressure
  • Diameter 15 to 22mm - 40 Bar
  • Diameter 28 to 35mm - 25 Bar
  • Diameter 42 to 108mm - 16 Bar
  • Diameter 140 to 168mm - 25 Bar
Multiple Applications
  • Hydrocarbons
  • Hot & Cold Water
  • Fire System
  • Conduits
  • Compressed Air
  • Gases
  • Chemicals & More
  • Cut
  • Deburr
  • Witness Mark
  • Assemble
  • Press (15 SEC 15mm -35 mm)
Select the 'O'Ring that is suitable for your application.

PLEASE NOTE: For O-ring recommendations on non-standard applications please refer to Technical Department.

'O'Ring Applications Marking Temperature Range
EPDM Black Water & Other -30°C to 120°C
FKM (Viton) Green Industrial & Other HT -20°C to 200°C
HNBR Yellow Gas Gas -20°C to 95°C

For ordering FKM Viton or HNBR please add HT or G to the codes. eg: IMSE28HT
